Mini Screw-Clamp Eco-Friendly Waterproof Box F1-4T

The Mini Screw-Clamp Eco-Friendly Waterproof Box F1-4T is a compact junction box featuring a screw-clamp wiring structure for fast and secure cable connection. Designed for outdoor electrical applications, it combines convenient installation with waterproof protection.

VIEW MORE Information VIEW MORE Specifications VIEW MORE Contact Us

Core Functions
Screw-Clamp Connection
The built-in clamp structure simplifies cable connection and improves wiring stability.
Eco-Friendly Housing
The housing material provides reliable insulation while supporting environmentally conscious applications.
Waterproof Protection
The sealed structure protects internal components from moisture and dust.
Multi-Cable Distribution
The four-way design supports flexible cable routing and connection.

Specific Applications
The F1-4T Screw-Clamp Waterproof Box is suitable for outdoor lighting, photovoltaic equipment, garden systems, and automation wiring.

Item Specification
Protection Rating IP68
Temperature Resistance -40°C to +105°C
Storage Temperature Ambient
Body Material PA6 Nylon (Flame-retardant)
O-ring Material Silicone (Eco-friendly)
Applicable Cable Range Φ3–6.5 mm, Φ5–8 mm, Φ7–10 mm (3 gland plug sizes available)
Wiring Method Screw Terminal
Conductor Material 59-1 Brass
Applicable Wire Gauge 0.5–2.5 mm²
Withstand Voltage 1500V
Voltage/Current 24A / 450V
Flame Retardancy Rating UL-94V0
